Mobile HD Streaming & Broadcast

Mobile Broadband, Media Broadcast - MB² model 21Q is a portable backpack form-factor wireless video streaming platform enabled by our proprietary bonding encoder, capable of bonding GSM+Satcom+Wifi channels for true diversity and uninterrupted live HD quality video anywhere, anytime for Streaming & Broadcast.

➤  Multi-Channel bonding utilizing 6 x GSM/LTE modems
    + Wifi + 5G Option [&] satcom ready
➤  Hardware video encoding
➤  Internal hot-swap battery
➤  Integrated Multi GPS [&] remote management
➤  Optional two simultaneous video streams with priority M&C channel

●  Professional broadcast video
●  Realtime high quality Video Encoding
●  Robust transmission of Video [&] Audio
●  Auto configuration mode
●  Cloud or on-premise Media Server

MB² 21Q is a portable Electronic News Gathering system for Realtime high quality video encoding capable of Bonding any mix of 3G/4G/LTE, Satellite, WiFi and wired Internet to provide seamless uninterrupted broadband transmission.

●  Live Breaking News
●  Live Interviews
●  Live Sports

●  HDMI, HD (BNC), SDI (BNC), Analog (Composite) (BNC)
●  HD/SDI, SD/SDI, PAL/NTSC
●  H.264 AVC / H.265 Ready
●  1080i, 720p, 720x576, 720i
●  QCIF (176x144), CIF (352x288), SD (720x576i)
●  HD (1920x1080i)
●  HDMI, SDI, Composite, TS-H.264 Recording
●  256 Kbps - 12 Mbps | 4sec - 6 sec

●  XLR L/R - 4 CH Balanced Input
●  HE-MC, LC-MC
●  48 Kbps - 512 Kbps / Mic and earphone jack
●  Two way voice communication / Intercom / Talk Back

●  Up to 6 embedded 3G/4G modems
●  Up to 6 external 3G/4G/CDMA
●  6 easy to reach embedded SIM card slots
●  New SIM card Plug [&] Run

●  VBR (Variable bit rate)
●  FEC (Forward error correction)
●  Store [&] Forward / Background Sync Store Forward
●  File Transfrer capable in both directions
     < client to server or server to client >

WEBCORE

WEBCORE is a media center platform which enables configuration, orchestration and monitoring streaming content from the multiscreen control Interface. The MB² broadcast terminals can be configured and managed from multiple locations. Mitigating the need for support personnel in the field, broadcast terminals can be configured, controlled and monitored from the broadcaster's management center.

●  MB² enables login to your social media live broadcast account from the WEBCORE interface.

●  Stream directly to your TV channel, WEBTV and other accounts simultaneously.

Cloud Server or "On Premise" Hardware Server ?

MB² Cloud Server provides high availability cloud based virtual resources to deliver HD media content reliably to its destination. No physical hardware is required other than your computer or tablet to configure the connection.

MB² Hardware Server enables secure content delivery to a dedicated hardware "On-Premise" platform. The content is directly accessible via SDI interface. There is also an interface for two-way voice communication / Intercom / Talk Back with field personnel.
